Electrical Parameters (Under Standard Test Conditions)
Maximum Power-Pmax(Wp)
350
Power Tolerance-Pmax(W)
0~+3
Operating Voltage-Vmpp(V)
30
Operating Current-Impp(A)
8.43
Open Circuit Voltage-Voc(V)
36.2
Short Circuit Current-Isc(A)
10.2
Module Efficiencynm(%)
14.2
Measured under Standard Test Conditions (Air MassAM1.5, Irradiance1000W/㎡, Cell Temperature25°C)
Measurement Tolerance: ±3%
Mechanical Parameters
Cell Type
Monocrystalline
Number of Cells
60
Module Dimensions
1640*990*35
Weight
23KG
Glass
3.2mm Ultra-clear Textured Tempered Glass
Encapsulation Material
EVA
Backsheet
TPT White
Frame
