Electrical ParametersSTC(Under Standard Test Conditions) DLXN-M10-100W
Maximum Power-Pmax(Wp)
100
Power Tolerance-Pmax(W)
0~+3
Operating Voltage-Vmpp(V)
21.03
Operating Current-Impp(A)
4.76
Open Circuit Voltage-Voc(V)
24.47
Short Circuit Current-Isc(A)
5.02
Module Efficiencynm(%)
17.0
Measured values under standard test conditions (Air MassAM1.5, Irradiance 1000W/㎡, Battery Temperature 25°C)
Measurement Tolerance: ±3%
Mechanical Parameters
Cell Type
Monocrystalline
Number of Cells
36
Module Dimensions
940*580*25
Weight
5.83KG
Glass
3.2mm Ultra-White Textured Tempered Glass
Encapsulation Material
EVA
Backsheet
TPT White
Frame
25mm Aluminum Frame
Junction Box
Protection ClassIP67
Cable
Optional0.5-4mm² Copper Wire
Connector
OptionalMC4, Waterproof Terminal, Wire Clip
Temperature Rating
Limit Parameters
NOCT (Nominal Operating Cell Temperature)
45.3℃
Operating Temperature
-40-+85℃
Temperature Coefficient of Maximum Power(Pmax)
-0.41%/℃
Maximum System Voltage
1000VDC
Temperature Coefficient of Open Circuit Voltage(VOC)
-0.34%/℃
Maximum Fuse Rating
10A
Temperature Coefficient of Short Circuit Current(ISC)
0.06%/℃
